TM1000 Thermoforming Machine
Send us your application details. Our engineering and sales team will contact you regarding TM1000 Thermoforming Machine.
Machine Code: TM1000
Dimensions:
Length: 16.50 m (4 stations) / 14.75 m (3 stations)
Width: 3.60 m (with electrical cabinet)
Height: 2.95 m
Weight: 16,500 kg (3 stations) / 18,000 kg (4 stations)
Sheet Width: max 1,040 mm (+110 mm stretch)
Sheet Thickness: 0.2 – 3.0 mm
Product Height: Positive 140 mm / Negative 140 mm
Cycle Speed: up to 50 cycles/min (dry-run)
Mold Area: 1,000 × 750 mm
Clamping Force: Forming 90,000 daN | Punching 95,000 daN | Cutting 110,000 daN
Heater Power: 183 kW
Air Requirement (7 bar): 6 – 8 m³/min
Cooling Requirement: 30,000 Kcal/h
Vacuum Pump Capacity: 200 m³/h
Control Unit: Beckhoff
