Thermoforming Machine TM650
Send us your application details. Our engineering and sales team will contact you regarding Thermoforming Machine TM650.
Machine Code: TM650
Dimensions: 11.00 m (L) × 2.60 m (H) – Weight: 10,500 kg (3 stations) / 12,000 kg (4 stations)
Sheet Width: max 700 mm (+40 mm stretch)
Sheet Thickness: 0.2 – 1.5 mm
Product Height: Positive 130 mm / Negative 130 mm
Working Stroke: 140 mm
Material Types: PET, CPET, PP, PVC, PS, OPS, PLA
Cycle Speed: up to 80 cycles/min (dry-run)
Mold Size: 690 × 450 mm
Clamping Force: Forming 50 000 daN | Punching 60 000 daN | Cutting 65 000 daN
Heater Power: 84 kW
Installed Power: 120 kW (3 stations) / 130 kW (4 stations)
Air Requirement (7 bar): 6 – 8 m³/min
Cooling Capacity: 25 000 Kcal/h
Vacuum Pump: 100 m³/h
