TM800 Thermoforming Machine
Send us your application details. Our engineering and sales team will contact you regarding TM800 Thermoforming Machine.
Machine Code: TM800
Dimensions: 11.50 m (L) × 2.75 m (W, incl. electrical cabinet) × 2.85 m (H) – Weight: 13,500 kg (3 stations) / 14,500 kg (4 stations)
Sheet Width: max 840 mm (+60 mm stretch)
Sheet Thickness: 0.2 – 3.0 mm
Product Height: Positive 130 mm / Negative 130 mm
Cycle Speed: up to 75 cycles/min (dry-run)
Mold Area: 800 × 600 mm
Clamping Force: Forming 60,000 daN | Punching 75,000 daN | Cutting 80,000 daN
Heater Power: 110 kW
Air Requirement (7 bar): 6 – 8 m³/min
Cooling Requirement: 25,000 Kcal/h
Vacuum Pump Capacity: 200 m³/h
Control Unit: Beckhoff
