Converting Machines / Slitting Machines

PMH 1600 Slitting Machine

Name: PMH 1600 Slitting Machine
Brand: PME Turkey

Engineering SupportTell us your material, width, output and application. We help configure the right machine.

Worldwide DeliveryExport, installation and commissioning support for international projects.

After-SalesTechnical assistance and spare parts support.

Request Technical Offer WhatsApp

Product ID 266Category Slitting Machines

Product Information

PMH 1600 Slitting Machine

The PMH 1600 Slitting Machine is designed to handle high tonnage and large diameters in the unwinding unit while delivering high-speed operation and maximum quality in the rewinding unit. Equipped with advanced systems and a wide range of accessories, it ensures smooth processing even for demanding and complex production applications.

Technical Specifications:

Unwinding Reel Diameter: 1400 mm
Rewinder Reel Diameter: 800 mm
Working Width: 1000 mm / 1300 mm / 1600 mm
Unwinding Core Diameter: 76 mm (3”) / 152 mm (6”)
Rewinder Core Diameter: 76 mm (3”) / 152 mm (6”) (Optional)
Minimum Slitting Width: 50 mm (25 mm Optional)
Machine Speed: Up to 800 m/min

Slitting Systems:

Circular Knife Slitting System
Razor Blade Slitting System

Workable Materials:

Films: 12 – 180 micron (CPP, OPP, BOPP, BOPA, LLDPE, LDPE, HDPE, PET, PETP, PVC)
Laminates: Various materials up to 180 microns
Paper & Board: 20 – 250 gr/m²
Aluminum: Foil up to 180 microns

PMH 1600 Slitting Machine
