Converting Machines / Slitting Machines

PMF Slitting Machine

Name: PMF Slitting Machine
Brand: PME Turkey

Engineering SupportTell us your material, width, output and application. We help configure the right machine.

Worldwide DeliveryExport, installation and commissioning support for international projects.

After-SalesTechnical assistance and spare parts support.

Request Technical Offer WhatsApp

Product ID 264Category Slitting Machines

Product Information

PMF Slitting Machine

Thanks to its compact design, the PMF Slitting Machine provides significant space savings in production facilities while delivering maximum performance. Engineered for high-speed operation, it ensures superior slitting accuracy and excellent rewinding quality for a wide range of materials.

Technical Specifications:

Unwinding Reel Diameter: 800 mm
Rewinder Reel Diameter: 500 mm
Working Width: 1000 mm / 1300 mm / 1600 mm
Unwinding Core Diameter: 76 mm (3”) / 152 mm (6”)
Rewinder Core Diameter: 76 mm (3”) / 152 mm (6”) (Optional)
Minimum Slitting Width: 50 mm (25 mm Optional)
Machine Speed: Up to 800 m/min

Slitting Systems:

Circular Knife Slitting System
Razor Blade Slitting System

Workable Materials:

Films: 12 – 180 micron (CPP, OPP, BOPP, BOPA, LLDPE, LDPE, HDPE, PET, PETP, PVC)
Laminates: Various materials up to 180 microns
Paper & Board: 20 – 250 gr/m²
Aluminum: Foil up to 180 microns

PMF Slitting Machine

Request Technical Offer

Product Information
