PMB 1300 Slitting Machine
The PMB Series Slitting Machine is designed to deliver high-quality production with cost-effective investment for the flexible packaging industry. With its robust construction, precise tension control, and high-speed operation, it ensures excellent slitting accuracy and superior rewinding performance across a wide range of materials.
Technical Specifications:
- Unwinding Reel Diameter: 800 mm
- Rewinder Reel Diameter: 500 mm
- Working Width: 1000 mm / 1300 mm / 1600 mm
- Unwinding Core Diameter: 76 mm (3”) / 152 mm (6”)
- Rewinder Core Diameter: 76 mm (3”) / 152 mm (6”) (Optional)
- Minimum Slitting Width: 50 mm (25 mm Optional)
- Machine Speed: Up to 400 m/min
Slitting Systems:
- Circular Knife Slitting System
- Razor Blade Slitting System
Workable Materials:
- Films: 12 – 180 micron (CPP, OPP, BOPP, BOPA, LLDPE, LDPE, HDPE, PET, PETP, PVC)
- Laminates: Various materials up to 180 microns
- Paper & Board: 20 – 250 gr/m²
- Aluminum: Foil up to 180 microns
