Doypack Bag Making Machine
Send us your application details. Our engineering and sales team will contact you regarding Doypack Bag Making Machine.
Product Description:
The Doypack Bag Making Machine is a high-performance system engineered for the production of stand-up pouches and three-side sealed bags.
It provides precise cutting, sealing, and shaping for various flexible packaging materials such as PET, PE, CPP, and laminated films.
With automatic control, high-speed sealing, and modular feeding, the system ensures maximum productivity and consistent sealing quality.
Technical Specifications:
3 Side Welded Bag:
Bag Width: 70–380 mm (max intermittent feeding 6)
Bag Length: 50–350 mm
After 6 Feedings: Max. 2280 mm bag width
Production Speed: 180 pcs/min
Line Speed: 40 m/min
Doypack Bag:
Bag Width: 70–260 mm (3 times welded)
Bag Length: 100–350 mm
Gusset Depth: 20–60 mm
Production Speed: 100 pcs/min
Line Speed: 40 m/min
