4 Color Flexo Printing Machine
Send us your application details. Our engineering and sales team will contact you regarding 4 Color Flexo Printing Machine.
The 4 Color Servo Flexo Printing Machine is designed for high-precision and high-speed printing on flexible packaging films. Equipped with a full servo system, it ensures stable color registration, low waste ratio, and consistent performance even at 300 m/min. It is compatible with a wide range of materials such as PE, PP, OPP, CPP, PVC, HDPE, LDPE, BOPP and metalized substrates, making it an ideal solution for food packaging, industrial films, shopping bags and lamination applications.
| Feature | Specification |
|---|---|
| Model Options | 800-4 / 1000-4 / 1200-4 / 1400-4 / 1600-4 / 2000-4 / 2500-4 |
| Printing Length | 250 – 900 mm |
| Max. Printing Width | Up to 1200 mm (depends on model) |
| Main Roller Width | Up to 1250 mm (depends on model) |
| Printing System | 4 Color Servo System |
| Plate Thickness | 1.14 mm (optional: 2.54 – 2.84 mm) |
| Unwind / Rewind Diameter | Max. 1150 mm |
| Printing Speed | 20 – 300 m/min |
| Printing Configuration | 4+0 / 3+1 / 2+2 |
PE • PP • OPP • CPP • PVC • HDPE • LDPE • BOPP • Metalized Paper • Gelatin • Tellure Paper
