In-line Macro Punch Units

Name: In-line Macro Punch Units
Brand: PME Turkey

Engineering SupportTell us your material, width, output and application. We help configure the right machine.

Worldwide DeliveryExport, installation and commissioning support for international projects.

After-SalesTechnical assistance and spare parts support.

Product ID 101Category Hole Punch Machine

Product Information

High-Speed Drilling Machine

Drilling Speed: 120 m/minute (maximum)
System Operation: Utilizes high-speed pneumatic cylinders.
Control Type: PLC (Programmable Logic Controller)
Adjustability: Hole spacing can be customized to desired dimensions via the touch screen.
Individual Hole Adjustment: Each hole distance can be adjusted separately.
Valve Control: Opening and closing times are adjusted through the touch screen.
Pattern Control: Each punching pattern can be activated or deactivated from the screen.
Printed Product Recognition: Photocell system implemented for printed products.
Mobility: The system is mounted on a mobile chassis.
