Embossing Machine

Name: Embossing Machine
Brand: PME Turkey

Engineering SupportTell us your material, width, output and application. We help configure the right machine.

Worldwide DeliveryExport, installation and commissioning support for international projects.

After-SalesTechnical assistance and spare parts support.

Product ID 161Category Embossing Machines

Product Information

Embossing Machine Technical Specifications

Embossing System

Roller Width: 500mm, offering a wide processing capacity.
Embossing Width: 450mm, ideal for precise embossing operations on products.
Pattern: Diamond-patterned embossing roller, creating aesthetic and attractive designs.
Cooling: Equipped with a water cooling inlet, effectively controlling the roller temperature.
Drive System: Speed controlled, allowing for optimal speed settings during the process.
Motor Type: AC, providing powerful and efficient performance.
Opening/Closing: Operated by pneumatic cylinders for ease of use.
Heating: Equipped with a resistance heated hot air unit, bringing the material to processing temperature.
Tension Control: AC motor-driven, automatically adjusts the tension of the coil.

Warp System

Coil Mounting: Air shaft for easy and quick coil change.
Edge Control: Automatic edge control system ensures the material progresses smoothly.
Winding System: AC motor-driven, on-shaft winding, for neat and precise coil winding.
Speed: Up to 40mt/min, high production capacity.
Control Panel: Touchscreen PLC display, user-friendly interface and easy adjustments.
